Omni.Net Lite User’s Guide

Chapter 4 Using Tone Commands

70

4.3 Configuring Example with Tone Commands

This section shows you some examples of configuring the TA using Tone commands. Refer to

Chapter 2 on page 24

for more information about these TA features.

4.3.1 Phone Number Assignment

Use the

***310*[*]#

tone command to assign a phone

number to the PHONE port to which the telephone is attached. For example, dial

***130*5009001#

to assign 5009001 to the analog port.

221*n#

!pP1

Set outgoing call screen mode for the analog port.
n=0: No restriction (default).
n=1: Prohibit all outgoing calls.
n=2: Only accept the calls with the prefix in the pre-defined

list (see 35d*#).
n=3: Only reject the calls with the prefix in the pre-defined

list (see 35d*#).

222*n#

!pP2

Select CLIP (Calling Line Identification Presentation) or

CLIR (Calling Line Identification Restriction) for the analog

port.
n=0 indicates you select CLIR and the ISDN switch will not

pass your phone number to the destination site.
n=1 indicates you select CLIP and the ISDN switch will pass

your phone number to the destination site.

310*

[*]#

!pS

Assign your phone number to the analog port.
: Enter up to 32 characters, including digits

from 0 to 9, *, #, hyphen ( -), comma (,) and (‘,’). [‘,’] will be

ignored.
: Enter up to 20 ASCII characters ranging

from “0-9”,” a-z” and “A-Z”.

32d*

[*]#

!pId

Create a list of the incoming call phone number via the

analog port.
d=0-4: phone number index.
: Enter up to 32 characters, including digits

from 0 to 9, *, #, hyphen ( -), comma (,) and (‘,’). [‘,’] will be

ignored.
: Enter up to 20 ASCII characters ranging

from “0-9”,” a-z” and “A-Z”.

35d* #

!pOd

Create a list of the outgoing call prefix digits via the analog

port.
d=0-2

Table 22 Tone Commands

TONE COMMAND

AT COMMAND

DESCRIPTION
