Omni.Net Lite User’s Guide
Chapter 2 Using the Utility
42
Figure 16 RS-232 Port: Advance Setting
The following table describes the labels in this screen.
Table 8 RS-232 Port: Advance Setting
LABEL
DESCRIPTION
Advance Options
Auto Answer
Set how many ringing messages the TA receives before it answers a data call
automatically.
Enter 0 to stop the TA answering a data call automatically. When there is an
incoming data call, you can press the push button on the top panel (see the
Quick Start Guide) or use the
ATA
command to answer it manually.
Wait for Conn
Enter the number of seconds for the TA to wait for an answer to the data call
before dropping it.
Power on baud rate
Configure the initial baud rate after power-on.
Power on attribute
Configure the initial attribute of the data port after power-on.
Extended result code
Select extended result code to show the extended command response or the
connect message to the DTE (see
). Otherwise, select
basic result code (default).
Ring result code
Select the information you want to display for the incoming calls. Options are
no extended information (default), display calling phone number, display
user data, display calling phone number and user data and RVS-COM
format.
Charge Information
