P-660HW-D Series User’s Guide
Chapter 13 Bandwidth Management 194
13.10 Bandwidth Monitor
To view the ZyXEL device’s bandwidth usage and allotments, click Advanced > Bandwidth
MGMT > Monitor. The screen appears as shown. Select an interface from the drop-down list
box to view the bandwidth usage of its bandwidth rules. The gray section of the bar represents
the percentage of unused bandwidth and the blue color represents the percentage of bandwidth
in use.
Protocol Select the protocol (TCP or UDP) or select User defined and enter the protocol
(service type) number. 0 means any protocol number.
Back Click Back to go to the previous screen.
Apply Click Apply to save your changes back to the ZyXEL device.
Cancel Click Cancel to begin configuring this screen afresh.
Table 78 Services and Port Numbers
SERVICES PORT NUMBER
ECHO 7
FTP (File Transfer Protocol) 21
SMTP (Simple Mail Transfer Protocol) 25
DNS (Domain Name System) 53
Finger 79
HTTP (Hyper Text Transfer protocol or WWW, Web) 80
POP3 (Post Office Protocol) 110
NNTP (Network News Transport Protocol) 119
SNMP (Simple Network Management Protocol) 161
SNMP trap 162
PPTP (Point-to-Point Tunneling Protocol) 1723
Table 77 Bandwidth Management Rule Configuration (continued)
LABEL DESCRIPTION
