P-660HW-Tx v2 Series Support Notes

Step 3: You can modify the rule by clicking the button ‘Edit’ on the rule:

Key Settings:

RuleName

Give this rule a name, for example, 'WWW'

BW Budget

Configure the bandwidth you would like to allocate to this rule

Priority

Enter a number between 0 and 7 to set the priority of this class. The

higher the number, the higher the priority. The default setting is 3.

Use All
Managed
Bandwidth

Check this box if you would like to let this class to borrow bandwidth from

it's parents when the required bandwidth is higher than the configured

amount. Do not check this if you want to limit the bandwidth of this class

at the configured value.(Please note that you should also disable

Maximize Bandwidth Usage on the interface to meet the condition.)

Service

Select User-defined, SIP, FTP, or H.323 to specify the traffic types

Destination
IP Address

Enter the IP address of destination that meets this class.
