P-660R-T Series User’s Guide
231 Chapter 28 IP Policy Routing
Figure 156 Menu 25.1.1 IP Routing Policy
Menu 25.1.1 - IP Routing Policy
Policy Set Name= test
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Normal Packet length= 40
Precedence = 0 Len Comp= Not Equal
Source:
addr start= 1.1.1.1 end= 1.1.1.1
port start= 20 end= 20
Destination:
addr start= 2.2.2.2 end= 2.2.2.2
port start= 20 end= 20
Action= Matched
Gateway addr = 192.168.1.1 Log= No
Type of Service= Max Thruput
Precedence = 0
Press ENTER to Confirm or ESC to Cancel:
The following table describes the fields in this menu.
Table 73 Menu 25.1.1 IP Routing Policy
FIELD DESCRIPTION
Policy Set Name This is the policy set name assigned in Menu 25 – IP Routing Policy Setup.
Active Press [SPACE BAR] and then [ENTER] to select Yes to activate or No to
deactivate the policy. Inactive policies are displayed with a minus sign “-“ in SMT
menu 25.
Criteria
IP Protocol IP layer 4 protocol, for example, UDP, TCP, ICMP, etc.
Type of Service Prioritize incoming network traffic by choosing from Don’t Care, Normal, Min
Delay, Max Thruput, Min Cost or Max Reliable.
Precedence Precedence value of the incoming packet. Press [SPACE BAR] and then
[ENTER] to select a value from 0 to 7 or Don’t Care.
Packet Length Type the length of incoming packets (in bytes). The operators in the Len Comp
(next field) apply to packets of this length.
Len Comp Press [SPACE BAR] and then [ENTER] to choose from Equal, Not Equal,
Less, Greater, Less or Equal or Greater or Equal.
Source:
addr start / end Source IP address range from start to end.
port start / end Source port number range from start to end; applicable only for TCP/UDP.
Destination:
addr start / end Destination IP address range from start to end.
port start / end Destination port number range from start to end; applicable only for TCP/UDP.
Action Specifies whether action should be taken on criteria Matched or Not Matched.
