P-660R-T Series User’s Guide
Chapter 18 Remote Node Configuration 150
Figure 79 Menu 21 Filer Set Configuration
Menu 21 - Filter Set Configuration
Filter Filter
Set # Comments Set # Comments
------ ----------------- ------ -----------------
1 _______________ 7 _______________
2 NetBIOS_WAN 8 _______________
3 NetBIOS_LAN 9 _______________
4 IGMP 10 _______________
5 _______________ 11 WebSet1
6 _______________ 12 WebSet2
Enter Filter Set Number to Configure= 0
The following figures display the filter rules in filter sets 11 and 12.
Figure 80 Menu 21.11 WebSet 11
Menu 21.11 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- ----------------------------------------------------------- - - -
1 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=161 N D N
2 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=162 N D F
3 N
4 N
5 N
6 N
Enter Filter Rule Number (1-6) to Configure:
Figure 81 Menu 21.12 WebSet 12
Menu 21.12 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- ----------------------------------------------------------- - - -
1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=23 N D N
2 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=21 N D N
3 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=69 N D N
4 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=80 N D N
5 N
6 N
Enter Filter Rule Number (1-6) to Configure
