P-660R-T Series User’s Guide
165 Chapter 21 Network Address Translation (NAT)
Figure 96 Menu 15.1 Address Mapping Sets
Menu 15.1 - Address Mapping Sets
1. ACL Default Set
2.
3.
4.
5.
6.
7.
8.
255. SUA (read only)
Enter Menu Selection Number:
21.3.1.1 SUA Address Mapping Set
Enter 255 to display the next screen (see also Section 21.1 on page 162 ). The fields in this
menu cannot be changed.
Figure 97 Menu 15.1.255 SUA Address Mapping Rules
Menu 15.1.255 - Address Mapping Rules
Set Name= SUA
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- ------------- ----
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server+
3.
4.
5.
6.
7.
8.
9.
10.
Press ENTER to Confirm or ESC to Cancel:
The following table explains the fields in this menu.
Note: Menu 15.1.255 is read-only.
Table 51 SUA Address Mapping Rules
FIELD DESCRIPTION
Set Name This is the name of the set you selected in menu 15.1 or enter the name of a new set
you want to create.
Idx This is the index or rule number.
Local Start IP Local Start IP is the starting local IP address (ILA).
Local End IP Local End IP is the ending local IP address (ILA). If the rule is for all local IPs, then
the Start IP is 0.0.0.0 and the End IP is 255.255.255.255.
