P-660R-T Series User’s Guide
Chapter 21 Network Address Translation (NAT) 174
Figure 108 Example 3: Menu 15.1.1.1
Menu 15.1.1.1 Address Mapping Rule
Type= One-to-One
Local IP:
Start= 192.168.1.10
End = N/A
Global IP:
Start= 10.132.50.1
End = N/A
Server Mapping Set= N/A
Press ENTER to Confirm or ESC to Cancel:
Figure 109 Example 3: Final Menu 15.1.1
Menu 15.1.1 - Address Mapping Rules
Set Name= Example3
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- -------------- -------------- --------------- -------------- -----
1. 192.168.1.10 10.132.50.1 1-1
2 192.168.1.11 10.132.50.2 1-1
3. 0.0.0.0 255.255.255.255 10.132.50.3 M-1
4. 10.132.50.3 Server
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
Now configure the IGA3 to map to our web server and mail server on the LAN.
1 Enter 15 from the main menu.
2 Enter 2 in Menu 15 - NAT Setup.
3 Enter 1 in Menu 15.2 - NAT Server Sets to see the following menu. Configure it as
shown.
