GS-2750 User’s Guide

65

C

H A P T E R

6

System Status and Port

Statistics

This chapter describes the system status (web configurator home page) and port details
screens.

6.1 Overview

The home screen of the web configurator displays a port statistical summary with links to each
port showing statistical details.

6.2 Port Status Summary

To view the port statistics, click Status in all web configurator screens to display the Status
screen as shown next.

Figure 22 Status
