Page 129

Chapter 15 Link Aggregation

GS-2750 User’s Guide

129

15.4 Link Aggregation Setting

Click Advanced Application > Link Aggregation > Link Aggregation Setting to display
the screen shown next. See

for more information on link

aggregation.

Figure 58 Advanced Application > Link Aggregation > Link Aggregation Setting

Aggregator ID

Link Aggregator ID consists of the following: system priority, MAC address, key, port

priority and port number. Refer to

for more information on

this field.

Status

This field displays how these ports were added to the trunk group. It displays:
•

Static - if the ports are configured as static members of a trunk group.

•

LACP - if the ports are configured to join a trunk group via LACP.

Table 36 Advanced Application > Link Aggregation Status (continued)

LABEL

DESCRIPTION
