2 Unwinder / Winder Operation
100kg Unwinder / Winder User Guide 17
b. When using a roll paper where the print surface is on the inside.
Damage and problems that occur because of the use of roll media where the print surface is
on the inside are not covered by the warranty.
1
2
3
2
1
3
Figure 23. Install Roll Media
No. Part name
1 Roll Media
2 Unwinder Tension Bar Roller
3 Rear Printer Platen
