Parameter Description Default
Dial Prefix Contains the dial string pattern
matching used to distinguish and
route calls to a VoIP service
provider.
The default for My VoIP Account is
null (that is, all calls are routed via
this account, unless preceded by a
prefix defined for accounts two
through four).
Accounts 2 through 4 can be
configured with prefixes that are
used to invoke these accounts. The
dial string pattern match is in the
standard form. Prefix strings of #8,
#9, 8 and 9, if specified, are
automatically removed from the
dialed number. Other prefixes can
be altered through the substitution
flexibilities of the pattern matching
strings.
Preferred Codecs Allows listing, in order of preference,
the Codec code points preferred for
use with the service provider.
Menu options are: G.711u, G.711A,
G.729B, and iLBC.
The codecs listed here must also
be included in the
Preferred Codecs
list under Audio Settings on the VoIP
Parameters page.
If any codecs are listed here, then
only those codecs will be
negotiated. If no codecs are listed
here, then all Preferred Codecs
options will be negotiated.
Accounts 2, 3, and 4
Parameter Description Default
Turn My VoIP Service Enables or disables this account Disabled
My VoIP Provider Name Name of VoIP provider
16 X6v VoIP Features Technical Reference
