Physical Data
ND360, 480 & 600 Physical Data
Component
Models
ND360
ND480
ND600
1
1
ND600 and M1CZ600A Combined
Nominal Tonnage
30
40
50
DIMENSIONS (inches)
Length
100.1
103.1
105.1
Width
38.1
45.4
53.7
Height
74.6
89.4
99.0
WEIGHTS
2
(lb)
2
Motor, Motor Drive and Motor Overload Kits must be ordered separately,
The Motor, Motor Drive and Overload Kits are to be field installed.
Unit Shipping
1122
1246
1684
Unit Operating With
5 hp Motor and Drive
1184
---
---
7.5 hp Motor and Drive
1208
1348
1742
10 hp Motor and Drive
1224
1364
1859
INDOOR BLOWER
Diameter x Width
18 X 18
18 X 18
20 x 18
Qty.
2
2
2
INDOOR COIL
Face area (Sq. Ft.)
25.8
33.3
41.3
Rows
4
4
4
Fins per inch
16
16
16
Tube diameter
3/8
3/8
3/8
Circuitry Type
Interlaced Interlaced Interlaced
Refrigerant Control
TEV
TEV
TEV
SYSTEM DATA
No. Refrigeration Circuits
2
2
2
Suction Line OD (in.)
1 1/8
1 3/8
2 1/8
Liquid Line OD (in.)
7/8
7/8
7/8
FILTERS
Size and Quantity Per Model (In.)
16 x 20 x 2
---
6
---
20 x 20 x 2
---
3
---
20 x 22 x 2
---
---
---
16 x 25 x 2
---
---
6
20 x 25 x 2
10
6
3
25 x 25 x 2
---
---
6
Face area (Sq. Ft.)
34.7
42.6
53.1
ACCESSORY
HOT WATER COIL DATA
Face area (Sq. Ft.)
21.2
27.2
27.2
Rows
2
2
2
Fins per inch
12
12
8
Tube diameter (Copper) OD (In.)
1/2
1/2
1/2
Connections (Supply and Return) OD (In.)
1 3/8
1 5/8
1 5/8
Weight (lb)
150
190
190
STEAM COIL DATA
Face area (Sq. Ft.)
18.2
---
---
Rows
1
---
---
Fins per inch
8
---
---
Tube diameter (Copper) (In.)
1
---
---
Connection, (NPTE) (In.)
Inlet
2
---
---
Outlet
1-1/2
---
---
Weight (lb)
160
---
---
