ND360, 480 & 600 Drive Kit Data
UNIT MODEL
DRIVE KIT
MODEL
NUMBER
BLOWER
RPM
RANGE
ADJUSTABLE MOTOR PULLEY FIXED BLOWER PULLEY BELTS
PITCH DIA.
(IN.)
BORE
(IN.)
PITCH DIA.
(IN.)
BORE
(IN.)
QTY.
PITCH
LENGTH
(IN.)
DESIGNATION
ND360
1LD0415 636 - 795 4.0 - 5.0 1 3/8 11.0 1 3/16 2 63.3 A62
1LD0407 668 - 827 4.2 - 5.2 1 3/8 11.0 1 3/16 2 63.3 A62
1LD0408 827 - 986 5.3 - 6.3 1 3/8 11.0 1 3/16 2 59.7 A59
ND480
1LD0409 607 - 776 4.3 - 5.5 1 3/8 12.4 1 3/16 2 85.1 B84
1LD0410 776 - 917 5.4 - 6.6 1 3/8 12.4 1 3/16 2 86.8 B85
ND600
1LD0411 692 - 833 4.8 - 6.0 1 3/8 12.4 1 3/16 2 78.6 B78
1LD0412 762 - 931 5.4 - 6.6 1 5/8 12.4 1 3/16 2 76.8 B75
ND360, 480 & 600 Motor Kit Data
UNIT MODEL HP MOTOR KIT MODEL NUMBER FRAME SIZE
VOLTAGE
(3PH-60-HZ)
ND360
5.0
2LR04605023
184
208/230/460
2LR04605032 208/230/460
2LR04605158 575
7.5
2LP04607133
213
208/230/460
2LP04607158 575
10
2LP04610133
215
208/230/460
2LP04610158 575
ND480
7.5
2LP04607133
213
208/230/460
2LP04607158 575
10
2LP04610133
215
208/230/460
2LP04610158 575
ND600
10
2LP04610133
215
208/230/460
2LP04610158 575
15
2LP04615133
254
208/230/460
2LP04615158 575
ND360, 480 & 600 Motor Overload Elements
1
1 These units are equipped from the factory with a correctly
sized motor starter; overload elements are not factory
supplied. Three elements required per unit.
MOTOR HP VOLTAGE MODEL NUMBER
5
208 2MP04704600
230 2MP04704600
460 2MP04704900
575 2MP04705000
7.5
208 2MP04703700
230 2MP04704500
460 2MP04704300
575 2MP04704000
10
208 2MP04701600
230 2MP04704100
460 2MP04704200
575 2MP04704300
15
208 2MP04704400
230 2MP04701700
460 2MP04704500
575 2MP04704600
