York MILLENNIUM ND600 User Manual
Page 33
628767-YTG-C-0910
Johnson Controls Unitary Products
33
ND360/ND480 Details For Securing Suspension Channels
ND600 & M1CZ600 Weight Distribution With Suspension Application
3
NOTE: The following illustration shows how the channels
should be secured to the unit using the hardware
provided with the suspension accessory.
(2) 9/16 HOLES FOR 1/2
HANGER RODS
SUSPENSION
CHANNEL
5/16 NUT,
LOCKWASHER,
FLATWASHER
UNIT PANEL
5/16 BOLT,
FLAT-WASHER
UNIT ANGLE
SIDE
PANEL
5/16 NUT,
FLATWASHER
3/8 NUT (USED
AS SPACER)
E
D
AX
C
BX
BX
B
A
F
