Unit Dimensions ND360
57.7
Ø0.88 KO
ELECTRIC HEAT
CONNECTION
15.9
4X Ø0.88 KO
CONTROLS
CONNECTION
3.0
9.1
5.3
22.0 62.4
22.0 22.5
5.3
2.6
19.0
SUPPLY
AIR
SUPPLY
AIR
100.1
95.6
2.4
33.2
7.3
6.7
Ø0.88 LIQUID
CONNECTION
SYSTEM 2
Ø1.125 SUCTION
CONNECTION
SYSTEM 1
Ø0.88 DRAIN
CONNECTION
Ø1.125 SUCTION
CONNECTION
SYSTEM 2
38.1
3.4
4.1
5.1
6.1
3.6
5.5
23.6
5.9
74.7
0.63
Ø0.88 LIQUID
CONNECTION
SYSTEM 1 RETURN
AIR
RETURN
AIR
