Specifications
Ribbon Specifications
11342L Rev. 8 6/4/2004 105SL User Guide 95
Ribbon Specifications
Font Specifications
203 dpi (8 dots/mm)
Ribbon Specifications 105SL
Ribbon must be wound with the coated side out.
Ribbon width (Zebra recommends using
ribbon at least as wide as the media to
protect the printhead from wear.)
Minimum 0.79 in. (20 mm)
Maximum 4.49 in. (114 mm)
Standard lengths 2:1 media to ribbon roll ratio 984 ft. (300 m)
3:1 media to ribbon roll ratio 1476 ft. (450 m)
Ribbon core inside diameter 1.0 in. (25.4 mm)
Maximum ribbon roll outside diameter 3.2 in. (81.3 mm)
Note • Bitmap fonts A through H and GS symbols are expandable up to 10 times, height and
width independent.
Smooth scalable font
∅ (CG Triumvirate™ Bold Condensed) is expandable dot-by-dot, height
and width independent.
IBM
®
Code Page 850 International Characters.
Fonts
Matrix (in dots)
(H × W)
Type*
Minimum Char. Size
(H × W)
Maximum
C.P.I.
A 9 × 5 U-L-D 0.044 in. × 0.029 in. 33.9
B 11 × 7 U 0.054 in. × 0.044 in. 22.6
C,D 18 × 10 U-L-D 0.088 in. × 0.059 in. 16.9
E 28 × 15 OCR-B 0.138 in. × 0.098 in. 10.1
F 26 × 13 U-L-D 0.128 in. × 0.079 in. 12.7
G 60 × 40 U-L-D 0.295 in. × 0.236 in. 4.2
H 21 × 13 OCR-A 0.103 in. × 0.093 in. 10.7
GS 24 × 24 SYMBOL 0.118 in. × 0.118 in. 8.4
∅ variable U-L-D variable N/A
* U = Uppercase; L = Lowercase; D = Descenders
