6–12 T R O U B L E S H O O T I N G
Media Jam Areas
Figure 6–1 illustrates the four areas where a media jam might occur.
Figure 6–1: Media Path
Fuser/Output Area
Transfer Drum/Print Drum Area
Input/Transfer Drum Area
Tray and Manual Feed Slot Area
Grounding Roller
WARNING: Exposure to prolonged periods of direct light may
damage the Print Drum. Close the printer covers promptly after you
have cleared a jam.
