Zebra Z4M/Z6M Printers User’s Guide 81
0®lY‹y‹YAП‹Ÿ›Ж
NOTE: Printer specifications are subject to change without notice.
*HQHUDO 6SHFLILFDWLRQV
General
Specifications
Z4M Z6M
Height 13.3" 338 mm 13.3" 338 mm
Width 10.9" 277 mm 13.4" 341 mm
Depth 18.7" 475 mm 18.7" 475 mm
Weight (without options) 32.4 lbs. 14.7 kg 34.7 lbs. 16 kg
Electrical 90-265 VAC, 48-62 Hz, 5 Amps (fused) 90-265 VAC, 48-62 Hz, 5 Amps (fused)
Agency Approvals UL 1950, CISPR 22 (class B), CSA 22.2 No. 950-95, EN60950, EN500824.
Complies with FCC Class B and Canadian Doc Class A rules.
Carries the CE mark of compliance.
Temperature Operating 40° to 104° F 5° to 40° C 40° to 104° F 5° to 40° C
Storage –40° to 140° F –40° to 60° C –40° to 140° F –40° to 60° C
Relative
Humidity Operating 20% to 85%, non-condensing 20% to 85%, non-condensing
Storage 5% to 85%, non-condensing 5% to 85%, non-condensing
8‚€€ˆvph‡v‚ÃD‡r shpr
• RS-232/CCITT V.24 and RS-485 serial data interface; 600 to 38400 baud,
parity, bits/character, and XON-XOFF or DTR/DSR handshake protocol
required.
• RS-485 serial data interface; 600 to 38400 baud, parity, bits/character
(all selectable). XON/XOFF handshake protocol required.
• 8-bit parallel data interface; supports IEEE 1284 bi-directional parallel
communication in “nibble mode.”
• Error detection CRC protocol.
