Video path diagnostics test – Xerox 470 User Manual
Page 186
Page 9 - 54
Xerox Document Centre Reference Guide
Video Path Diagnostics Test
The Video Path Diagnostics Test tests the circuitry and verifies the
electronic path involved in the process of moving the digitized
image to the Xerographic module.
To activate this test, press the Video Path Diagnostics button and
follow the instructions displayed on the User Interface.
Tools Screen 1
Tools Screen 2
Machine Tests
How to get here
Machine Tests
Video Path
Diagnostics
More
Test
Tools Screen 1
Machine Tests
(On a DC model)
Machine Tests
Video Path
Diagnostics
Test
