35 ■
Advanced
Operation
Foot switch settings: pages 7, 8
When the 8080 is in Manual mode or Edit mode, foot switches 1-5 can be used to switch effect modules on and
off. Pages 7 and 8 of the Utility mode serve to assign modules to the various switches.
Fsw ASSIGN: SW1=
7 SW2= SW3=
3 4
1 2
MAX MIN
MAX MIN MAX MIN
MAX MIN
q
w e
PAGE 7
q
w e
Fsw ASSIGN:
8 SW4= SW5=
3 4
1 2
MAX MIN
MAX MIN MAX MIN
MAX MIN
r t
PAGE 8
r t
UTILITY
PAGE
q SW1 (Switch 1) Sets the effect module to be controlled CMP, EF1, DST, EQ
by foot switch 1. EF2, EF3, DLY, REV
w SW1 (Switch 2) Sets the effect module to be controlled CMP, EF1, DST, EQ
by foot switch 2. EF2, EF3, DLY, REV
e SW1 (Switch 3) Sets the effect module to be controlled CMP, EF1, DST, EQ
by foot switch 3. EF2, EF3, DLY, REV
r SW1 (Switch 4) Sets the effect module to be controlled CMP, EF1, DST, EQ
by foot switch 4. EF2, EF3, DLY, REV
t SW1 (Switch 5) Sets the effect module to be controlled CMP, EF1, DST, EQ
by foot switch 5. EF2, EF3, DLY, REV
Parameters Comment Values
It is not possible to assign the same effect module to several foot switches. If this is attempted, the foot switch with the lowest number only is
active. For example, if the DST module was already assigned to SW1 and then SW3 is also set to "DST", the indication changes to lower case
("SW3=dst") and the setting will not be active until the setting of SW1 is changed.
NO
✎
The patches of the 8080 are divided into the USER group and the PRESET groups A, B and C. Only two groups
can be active at any one time: the USER group and one PRESET group. Page 9 of the Utility mode serves to
select the PRESET group A/B/C (called Folder A/B/C here).
Switching PRESET groups A/B/C: page 9
PRESET FOLDER SELECT
9 FOLDER = A
3 4
1 2
MAX MIN
MAX MIN MAX MIN
MAX MIN
PAGE 9
q
q
q FOLDER Selects the PRESET group (A, B, C) to be used in Play mode.
Parameters Comment
It is also possible to use the USER FUNCTION switch to select PRESET groups A/B/C during a performance ( p. 40).
NO
✎
