Environmental Specifications
975-0131-01-01 A–5
Environmental Specifications
User Display
Display Accuracy
Mechanical Specifications
Rated operating temperature range -25° to +45° C (-13° to +113° F)
Tolerable operating temperature
range -25° to +65° C (-13° to +149° F)
Storage temperature range -40° to +85° C (-40° to +185° F)
Power derating Derating curve above +45° C (+113° F);
see Figure A-1 on page A–3
Tolerable relative humidity limit Operating: 100% condensing
Storage: <95%, non-condensing
Type alphanumeric liquid crystal
Size 2 lines by 16 characters
Backlight yes
Instantaneous Power +/- (30 W + 1% of reading)
Voltage +/- (1% of rating + 1% of reading)
Current +/- (1% of rating + 1% of reading)
System Lifetime energy +/- 5%
Outdoor enclosure NEMA 3R, Rainproof
Inverter dimensions
(H × W × D) 72.5 Ч 40.3 Ч 14.6 cm (28.5 Ч 15.9 Ч 5.7 inches)
Shipping dimensions
(H × W × D) 86.6 Ч 51.8 Ч 26.2 cm (34 Ч 20.4 Ч 10.3 inches)
Inverter weight 20.4 kg (45 lb)
Shipping weight 26.6 kg (58.7 lb)
Input and output terminals
AC and DC terminals accept wire sizes of 2.5 to 25 mm
2
(#14 to #6 AWG)
Disconnect switch Integrated switch, disconnects both AC and DC (meets
NEC article 690), rated @ 600 Vdc
