030-300354 Rev. B 115 July 2003
Section 16-Help
Westell Dual Connect NAT Router User Guide
Detect WAN Configuration
This screen displays the Protocols detected by the Dual Connect NAT Router.
Detect WAN Configuration
DHCP Results Detects the protocol type used to connect your modem to the network.
PPPoE Results Detects the protocol type used to connect your modem to the network.
Last VC Tested (VPI/VCI) Displays the VPI/VCI settings your modem detected to network the Router
connection.
DHCP Configuration
This screen contains the settings which control how the ADSL router interacts with the local devices connected to
the router. Westell does not recommend that you change these settings. The following settings are displayed.
DHCP
DHCP Server Dynamic Host Configuration Protocol (DHCP) is an Internet
standard that allows the ADSL router to automatically assign IP
addresses to devices connected on the LAN network. It is advised
that this is enabled for Private LAN.
DHCP Start Address (If DHCP is
enabled) This setting specifies the start of the IP address pool that the modem
uses to assign IP addresses to local devices.
DHCP End Address (If DHCP is
enabled) This setting specifies the end address of the IP address pool used for
automatic configuration of local devices.
DHCP Lease (If DHCP is enabled) This setting specifies the DHCP lease time.
DNS Configuration
The Router has a built-in DNS server. The Router has a feature called "Dynamic DNS." When an IP address is
assigned, the Router will interrogate the new device for a machine name using several well-known networking
protocols. Any names learned will dynamically be added to the DNS server’s table of local hosts. A static host
assignment is needed only if the new device does not support any of the well-known protocols. The following
settings are displayed.
DNS Configuration Screen
Domain Name The name of your network. This uses the internet standard for delineating
domain names.
Static Host Assignment This table allows the creation and maintenance of manually configured DNS
entries.
Dynamic Host
Assignment This table shows the current list of devices that have automatically provided
information.
