030-300354 Rev. B 110 July 2003
Section 16-Help
Westell Dual Connect NAT Router User Guide
16. HELP
If you select Help from the menu bar, a message from the help screens will be displayed. The type of message
displayed depends on the menu that you are viewing. If you are viewing a pop-up screen, click the help link in the
pop-up screen to obtain help messages.
A
About
This screen provides information about the Router. The following settings are displayed.
About
Model Number Router manufacturer's model number.
Serial Number Router manufacturer's serial number.
MAC Address Ethernet MAC (i.e., hardware) Address of the Router.
Software Version Router application software version number.
Software Model Router application type.
Description Description of the Router protocol processing application software.
Boot Loader Router boot loader version number.
Advanced Home Page
The advanced home page offers the same functionality as the home page but adds the ability to change the
connection profile settings defined in the Router.
About
Edit An “Edit” link is added for each connection profile. Selecting this link will
pop-up a window that allows the connection profile settings to be changed.
New Connection The “New Connection” link will pop-up a window to allow the creation of a
new connection profile.
ATM Loopback
ATM Loopback
ATM Loopback This setting enables 0/21 loopback. Westell recommends that you do not
change this setting.
