Page 71
BATTERY CART - OPTION
86037880 CHARIOT EXTRACTOR 01/16/07
5-70
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86078330
66478
1 PEDAL, BATTERY CART
2
86276070
70593
2 SCR, 5/16-18 X 3/4 CARRIAGE SS
3
86270830
57023
12 NUT, 5/16-18 HEX NYLOCK SS
4
86087800
730307
2 STIFFENER, PEDAL, BATTERY CART
5
86228840
09124
4 BEARING, FLANGED .314ID X .502OD
6 86259410 87206 6 WASHER, THRUST .51 ID X 1 OD X .063
7
86006560
70083
4 SCR, 5/16-18 X 1 HHCS SS
8
86077140
51404
2 LATCH, BATTERY CART
9
86226830
73268
2 SPRING, EXT .68D X 3.00L X .098W
10 86010670
87029
10 WASHER, 5/16 FLAT SS
11 86244280 500934 1 LABEL,
BATTERY CAR OPERATION
12 86276060
70590
4 SCR, 5/16-18 X 2.5 CARR GR5
13 86254280
730331
12 SPACER, 1.00 ODX .32ID X .375
14 86231150
09151
4 BUSHING FLANGE, .314 X .502 OD
15 86259400
87205
8 WASHER, THRUST .51 ID X 1 OD
16 86276690
70715
16 SCR, 5/16-18 X 1.75 CARR SS
17 86077530
51403
2 LINKAGE, LATCH, BATT CART
