Page 25
SCRUB DECK MOTORS
86037880 CHARIOT EXTRACTOR 01/16/07
5-24
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86277880
70855
8
SCR, M8-1.25 X 35 LG SHCS SS
2
86222330
57504
2
NUT, M8 -1.25 HEX JAM SS
3
86279790
87489
6
WASHER, M8 (THICK) FLAT SS
4
86137310
87098
6
WASHER, M8 SPLIT LOCK
5
86217710
29268
2
DOOR, CYLINDRICAL BRUSH
6
86219290
34418
2
HOUSING, SCRUB PLUS DRIVE
7
86219450
41488
2
HUB, TRI-STAR BRUSH IDLER
8
86223520
67598
2
RING, 28 MM INT SNAP PHOSPHATE
9
86228960
09149
4
BEARING, 15 X 28 X 7W SS BALL
10
86279770
87487
4
WASHER, M6 LARGE OD FLAT SS
11
86279140
87085
4
WASHER, M6 SPLIT LOCK DIN127B
12
86277870
70854
4
SCR, M6-1.0 X 20 LG BHSCS SS
13
86219440
41487
2
HUB, TRI-STAR BRUSH DRIVE
14
86279780
87488
2
WASHER, M16 SMALL OD FLAT SS
15
86004820
48041
2
KEY, 3/16 SQ X 7/8 CRS
