VACUUM SHOES
86037880 CHARIOT EXTRACTOR 11/15/08
5-38
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO. FROM
NOTES:
1
86006580
70085
10 SCR, 1/4-20 X 1/2 PPHMS SS
2
86075450
27246
1
COVER, VAC SHOE
3
86237910
35279
1
GASKET, VAC SHOE OUTER
4
86237920
35280
1
GASKET, 5.0 OD X 2.0 ID X .50T
5
86237930
35281
1
GASKET, VAC SHOE RIGHT
6
86237940
35282
1
GASKET, VAC SHOE CENTER
7
86237950
35283
1
GASKET, VAC SHOE WIPER
8
86295390
-
1
WIPER, VAC SHOE
*(5)
9
86275950
70568
4
SCR, 10-24 X 3/8 PPHMS SS
10 86293190
-
3 PIN,
CLEVIS
*(9)
11 86310740
-
1 WIPER,
W/GASKET
*(9)
12
86310750
-
1
ASSEMBLY, GASKETS, VAC SHOE
*(9)
13 86296410
-
1 PLATE,
VACSHOE
*(9)
14
86302700
-
10 SCR, M6 X 16 PH, SS
*(9)
15
86296550
-
1
VACSHOE, 13 IN
*(9)
* SEE SERIAL NUMBER PAGE
NOTE: Two vacuum shoe assemblies per machine.
