86037880 pg 5-22 and 5-23, Scrub deck – Windsor Chariot CE24 User Manual
Page 23
SCRUB DECK
86037880 CHARIOT EXTRACTOR 09/13/08
5-22
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86281150
39282
2
HOSE, 3/8 ID WIRE BOUND X 7”
2
86233150
20042
7
CLAMP, 3/8 HOSE (D-SLOT)
3
86281100
39274
1
HOSE, 1/2ID WIRE BOUND X 7”
4
86197760
78308
1
TEE, 1/4 STREET
5
86010730
87088
2
WASHER, 5/8 ID X 1.18 X .06 SS
6
86005580
56012
1
NIPPLE, 1/4 FPT QD
7
86197570
40028
1
HOSEBARB, 1/4MPT X 1/2 DL
8
86184900
790601
1
HOSEBARB, 1/4MPT X 1/2H 45 BR
9
86197590
40031
2
HOSEBARB, 1/8MPT X 3/8 90 D
10
86073620
67017
1
BRKT, JET MOUNT
11
86270830
57023
3
NUT, 5/16-18 HEX NYLOCK SS
12
86274290
70162
2
SCR, 10-32 X 3/8 PPHMS SS
13
86010640
87016
2
WASHER, #10 LOCK EXT STAR SS
14
86004570
44067
2
JET BODY, MINI PROMAX BODY
15
86241730
44107
2
JET MINI PROMAX 9506
16
86271870
57290
2
NUT, 1/4-20 HEX NYLOCK THIN SS
17
86010630
87013
4
WASHER, 1/4 ID X 5/8 OD SS
18 86255950 73869 1 STOP,
MOUNT
19
86092840
41535
1
HOPPER, CYL. SCRUB DECK 24
20
86258870
84168
1
VALVE, 120V 110 PSI SOLENOID
21
86197550
40014
2
HOSEBARB, 1/4MPT X 3/8 DL
22
86197730
78024
1
TEE, 1/4 BRANCH
23
86006530
70057
2
SCR, 1/4-20 X 1 PPHMS SS
24
86277150
70797
2
SCR, 5/16-18 X 2 BSHCS SS
25
86242120
48090
2
KNOB, 1.0 OD X 5/16-18
26
86260400
880212
1
WIRE ASM, REV POLARITY JUMPER
27
86002830
27196
2
CABLE TIE, .375 X 24.7
28
86217740
53815
2
DRIVE MOTOR (2 UNITS/CARTON)
29 - OPEN
-
-
30
86078060
149997
4
PAD, SKID BAR, LARGE
31
86277530
70861
8
SCR, M8 X 1.25 X 20LG BSHCS SS
32 86086100 66859 1 RETAINER,
DEFLECTOR
33
86006560
70083
3
SCR, 5/16-18 X 1 HHCS SS
34
86010670
87029
15 WASHER, 5/16 FLAT SS
35
86230500
02498
2
BRUSH, 24” CYL, C-NYLON
36 86064010 29270 1 DEFLECTOR,
MACHINED
37
86277530
70861
12 SCR, M8X1.25 X 20 LG BSHCS SS
38
86279130
87083
12 WASHER, 5/16 SPLIT LOCK PLTD
39
86270990
57090
4
NUT, 10-32 HEX NYLOCK SS
40
86010650
87018
4
WASHER, #10 X 9/16 OD
41 86197630 40042 1 HOSEBARB,
1/4MPT X 1/2H 90D DL
42 86264940 27051 3 CABLE
TIE,
11.38”
UL/CSA
43
86092540
34453
1
FRAME, EXTRACTOR DECK 24IN
