VACUUM SHOE LIFT HANDLE
86037880 CHARIOT EXTRACTOR 08/14/07
5-42
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86238360
36215
1
GRIP, 3/16 X 1.0 ORANGE
2 86076610 38319 1
HANDLE,
LIFT
3
86257120
72192
1
SWITCH, DPST SNAP ACTION
4
86008650
80604
1
COTTER, 1/4” RING
5
86279450
87161
2
WASHER, #6 FLAT SAE
6
86277490
70851
2
SCR, #6-32 X 1.38 PPHMS
7
86259420
87232
2
WASHER, THRUST .51D X 1 OD
8
86009560
82053
1
PIN, CLEVIS 1/4 X .63 PLTD
9
86270920
57049
2
NUT, 6-32 HEX NYLOCK SS
10
86007020
70673
1
SCR, 5/16-18 X 1.25 HHCS SS NP
11
86010670
87029
7
WASHER, 5/16 FLAT SS
12
86270830
57023
9
NUT, 5/16-18 HEX NYLOCK SS
13
86231150
09151
5
BUSHING FLANGE, .314 ID X .502 OD
14
86276760
70724
3
SCR, 5-16 X 1.25 BSHCS SS
15
86277460
70847
1
SCR, 5/16-18 X 5/8 BSHCS SS
16
86083440
66824
1
PLATE, PULLEY MOUNTING, CENTER
17
86223370
66464
4
PULLEY, PLASTIC 3.0 DIA
18
86231570
270105
1
CABLE, LIFT
19
86073600
66833
1
BRKT, PULLEY RETAINER, SINGLE
20
86083500
66832
1
PLATE, PULLEY RETAINER, CORNER
21
86083490
66831
1
PLATE, PULLEY MOUNT,CORNER
22
86066130
89501
1
ASM, HANDLE RETAINER
23
86254280
730331
1
SPACER, 1.00 OD X .32 ID X .375
24
86276070
70593
2
SCR, 5/16-18 X 3/4 CARRIAGE SS
25
86091820
140807
1
BRKT, SIDE CHANNEL R
26 86295860
-
1 INSULATOR,
SWITCH
*(6)
27
86274720
70264
1
SCR, 5/16-18 X 1.50 HHCS SS
* SEE SERIAL NUMBER PAGE
