Page 7
CONTROL PANEL-LOWER
86037880 CHARIOT EXTRACTOR 09/21/07
5-6
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86223740
70872
6
SCR, 1/4-20 X .59 PPHMS SS C
2
86273820
70019
2
SCR, 1/4-20 X 1.25 HHCS
3
86277480
70850
3
SCR, 5/16-18 X 1/2 PTHMS SS
4 86070720 140728 1
BRKT, BATT CONN, BASIC
5
86008760
80682
1
CONN, 175 DCA GRY W/O TERMS
6
86005810
57245
8
NUT, 1/4-20 HEX NYLOCK SS
7
86075310
61039
1
CONTROL PANEL, EXTRACTOR
8
86271840
57285
3
NUT, 5/16-18 HEX NYLOCK THIN SS
9
86006370
67315
3
RELAY, 36VDC 100AMP HVY DUTY
10
86010670
87029
6
WASHER, 5/16 FLAT SS
11
86279130
87083
6
WASHER, 5/16 SPLIT LOCK PLTD
12
86271120
57125
6
NUT, 5/16-18 BRASS
13
86005700
57104
8
NUT, 10-32 W/STAR WASHER PLTD
14 86027740 27911 1 CONTROLLER, GEAR DRIVE BASIC
