86037880 pg 5-12 and 5-13, Frame-lower – Windsor Chariot CE24 User Manual
Page 13
FRAME-LOWER
86037880 CHARIOT EXTRACTOR 01/16/07
5-12
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86070750
140731
1
BRKT, LINKAGE, LEFT
2
86071130
140812
1
BRKT, TIP BRACE, LEFT, REAR
3
86070760
140733
1
BRKT, BRACE, LEFT FRONT
4
86276070
70593
16 SCR, 5/16-18 X 3/4 CARRIAGE SS
5 86092500 34428 1
FRAME,
MAIN
6
86197040
57264
4
NUT, 5/16-18 HEX ACORN PLTD
7
86279130
87083
4
WASHER, 5/16 SPLIT LICK PLTD
8
86270830
57023
20 NUT, 5/16-18 HEX NYLOCK SS
9
86071120
140811
1
BRKT, TIP BRACE, RIGHT, REAR
10
86071430
140863
1
BRKT, BRACE, RGT FRONT
11
86070740
140730
1
BRKT, LINKAGE, RIGHT
12
86079320
620101
2
PLATE, PAD RETAINER
13
86064300
140790
2
PAD, TIPPING BAR
14
86010670
87029
4
WASHER, 5/16 FLAT SS
15
86091420
05251
1
AXLE, REAR WELDMENT
16
86088760
75458
1
TRAY, SLIDE, LEFT
17
86088750
75457
1
TRAY, SLIDE, RIGHT
18
86079290
620097
2
PLATE, REAR COVER ADJ.
19
86010630
87013
4
WASHER, 1/4 ID X 5/8 OD SS
20
86271870
57290
4
NUT, 1/4-20 HEX NYLOCK THIN SS
21
86276950
70772
4
SCR, 1/4-20 X 3/4 CARRIAGE SS
