SCRUB DECK LIFT LINKAGE
86037880 CHARIOT EXTRACTOR 01/16/07
5-28
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86276070
70593
4
SCR, 5/16-18 X 3/4 CARRIAGE SS
2
86272380
66217
1
PIN, CLEVIS 3/8 X .75 PLTD
3
86010770
87143
5
WASHER, 7/16 ID X 1 D X .08 FLT SS
4
86005630
57022
5
NUT, 3/8-16 HEX NYLOCK THIN SS
5
86271530
57216
4
NUT, 3/8-27 HEX NYLOCK
6
86270830
57023
4
NUT, 5/16-18 HEX NYLOCK SS
7
86009400
81873
1
CHAIN, #41 1/2” P MASTER LINK
8
86274660
70255
2
SCR, 3/8-16 X 1.5 HHCS GR5 PLT
9 86009050 81324 4
BEARING,
1/2 ID X 11/32L NYLON
10
86008460
80102
4
SPACER, .500 OD X .391 ID X .400
11
86093180
51415
1
LINKAGE ASM, DECK ARM
12
86224370
730335
4
SPACER, 1 OD X .391 ID X .500
13
86001320
140353
2
BALL JOINT ASSY, 3/8-24 LH
14
86005830
57263
2
NUT, 3/8-24 UNF LH
15
86223540
66483
2
ROD, SCRUB LIFT
16
86005800
57217
2
NUT, 3/8-24 HEX JAM
17 86008810
80697
2 BALL
JOINT ASY, 3/8-24 RH
18 86087580 73606 2
SPACER, 1/2 OD X .058 W X .26 LG
CRS
19
86254980
730312
1
SPRING, EXT 1.312D X 8.00L X .225 W
20
86026210
68023
1
PIVOT ARM, W/BEARINGS
21
86002850
27343
2
CHAIN, #40, 1/2 P MASTER LINK
22
86232820
27981
1
CHAIN, #40, 1/2 PITCH X 4 ROLLER
23
86009100
81396
2
WASHER FIBERGLIDE 1/2” ID X 1” OD
24
86257830
66879
1
TUBE, .50 OD X .377 ID X 1.656
25
86275840
70550
1
SCR, 3/8-16 X 2.5 HHCS GR5 PLTD
26
86279260
87119
1
WASHER, .53 ID X 1.0 OD X .060 PLTD
27
86008680
80607
1
COTTER, 1/2” RING
28
86093560
68021
1
PIVOT ASSY DECK LIFT
29
86271870
57290
2
NUT, 1/4-20 HEX NYLOCK THIN SS
30
86272320
66151
1
PIN, CLEVIS 1/2 X 2.75 LG
31
86270310
70760
2
EYEBOLT, 1/4-20 X 1.5 PLTD
