VACUUM HOSES

86037880 CHARIOT EXTRACTOR 01/24/09

5-44

REF

PART NO.

PRV NO.

QTY

DESCRIPTION

SERIAL NO.

FROM NOTES:

1

86240320

39729

1

HOSE ASM, 1.5 BLK VAC X 36

2

86177050 03-000176

3

CLAMP, HOSE #20

3

86320330

-

2

HOSE ASM, 1.5 BLK VAC X 12

4

86003010

27759

1

CUFF, HOSE 1.5” BLK A 2161

5

86264950

27746

2

CABLE TIE, .19 W X 11.5L BLK

6

86277460

70847

2

SCR, 5/16-18 X 5/8 BSHCS SS

7

86270830

57023

2

5/16 HEX NYLOCK SS

8 86093200 54212 1

MANIFOLD
