86037880 pg 5-36 and 5-37, Vacuum – Windsor Chariot CE24 User Manual
Page 37
VACUUM
86037880 CHARIOT EXTRACTOR 1/16/07
5-36
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86236540
34437
2
FOAM, POLY, 1/2 X 2 CURVED W/ADH
2
86238040
36243
4
GASKET, .25 T X .75 W X 24 L
3
86236530
34436
1
FOAM, POLYESTER, 1X3X18
4
86090140
270139
1
VAC CHANNEL COVER
5
86082110
62913
1
PLATE, CHAIN GUARD LT
6
86064740
270100
1
VAC CHANNEL COVER
7
86078650
36241
1
PLATE, CHAIN GUARD RT
8
86274070
70086
4
SCR, 10-24 X 1/2 PPHMS
9
86237890
35277
2
GASKET, VAC MOUNT
10
86237880
35276
2
GASKET, 5.7 VAC MOTOR
11
86005500
53809
2
VAC MOTOR 36VDC 3STG
12
86083100
66439
2
PLATE, HORIZ FLANGE RT
13 86083010 66428 2 PLATE,
VAC
SPACER
14
86270990
57090
8
NUT, 10-32 HEX NYLOCK SS
15
86270830
57023
6
NUT, 5/16-18 HEX NYLOCK SS
16
86083030
66430
2
PLATE, VAC MOTOR ADAPT
17
86270860
57028
4
NUT, 10-24 U-TYPE SPEED
