SCRUB DECK LIFT ACTUATOR
86037880 CHARIOT EXTRACTOR 09/14/07
5-26
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86011950
-
1
ACTUATOR, 36VDC, 3.5 IN STRK
*(1)
WAS 05250
2
86248980
81438
3
PIN, CLEVIS 3/8 X 1.75 PLTD
3
86006910
70443
2
SCR, 1/4-20 X 5/8 SHCS
4
86090330
87258
2
WASHER, .804ID X 1.25OD X .179
5
86278400
730351
1
SPRING, COMP., 1.10 OD X 2.25 L X 148
6
86066920
140852
1
BAR, COMP. SPRING RETAINER
7
86273820
70019
1
SCR, 1/4-20 X 1.25 HHCS SS
8
86070190
140581
2
BRKT, SCRUB DECK GUIDE 36V
9
86276760
70724
2
SCR, 5/16-18 X 1.25 BSHCS SS
10
86010670
87029
6
WASHER, 5/16 FLAT SS
11
86228840
09124
2
BEARING, FLANGED .314 ID X .502 OD
12
86259420
87232
4
WASHER, THRUST .51ID X 1OD
13
86091840
140850
1
BRKT, ACTUATOR SLIDER
14
86005810
57245
5
NUT, 1/4-20 HEX NYLOCK SS
15
86231360
14744
2
BUSH, BRZ FLG .25 X .38 X .25
16
86010630
87013
4
WASHER, 1/4 ID X 5/8 OD SS
17
86277500
70853
2
SCR, 1/4-20 X 5/8 CARR SS
18
86277130
70795
1
SCR, 5/16-18 X 1.00 CARRIAGE SS
19
86270830
57023
3
NUT, 5/16-18 HEX NYLOCK SS
20 86069440 140442 1
BRKT,
LATCH
21
86008670
80606
4
COTTER, 3/8” RING
22
86271280
57163
2
NUT, 4-40 W/STAR WASHER
23
86007160
72157
1
SWITCH, 10A ROLLER MINI
24
86087520
73456
2
SPACER, L2020B PLUNGER SWITCH
25
86072460
14387
1
BRKT, MICRO SWITCH MOUNT
26
86276010
70580
2
SCR, 4-40 X 1.0 PPHMS
27 86223270 66482 1
PLUNGER,
MICRO
SWITCH
28
86270270
27721
2
CLIP, RETAINING 7/16
29
86007780
73576
1
SPRING, COMP .60D X 2.0L X .045W
30
86005630
57022
1
NUT, 3/8-16 HEX NYLOCK THIN SS
31
86222270
57276
2
NUT, PUSH FLAT RD .51 ID
32
86255650
81627
2
SPROCKET, #41 1/2” P 9T
33
86229000
09154
2
BEARING FLG .377ID X .502 OD X .500
34
86272520
66392
1
PIN, CLEVIS 3/8 X 2.75 PLTD
35
86276400
70642
1
SCR, 3/8-16 X 3 HHCS
36
86010680
87030
4
WASHER, 3/8 ID X 3/4 OD NYLON
37
86228910
09139
2
BEARING, FLANGED .377 ID X .502 OD
38 86290090
-
1
GUARD,
CHAIN
*(2)
39
86232680
270114
1
CHAIN, #41, 1/2" PITCH X 34 P
40
86009400
81873
1
CHAIN, #41 1/2" P MASTER LINK
* SEE SERIAL NUMBER PAGE
