REAR COVER
86037880 CHARIOT EXTRACTOR 10/13/08
5-20
REF
PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86276780
70728
3
SCR, 5/16-18 X 3/4 HHCS SS
2
86279130
87083
5
WASHER, 5/16 SPLIT LOCK PLTD
3
86010670
87029
5
WASHER, 5/16 FLAT SS
4
86031790
270701
1
COVER, REAR
5
86005860
57273
2
NUT, 1/4-20 X 12MM HEX BARREL
6
86228980
09152
2
BEARING FLANGED .377ID X .505OD
7
86275870
70556
2
SCR, 1/4-20 X 1.5” PPHMS SS
WAS 70697
8
86242140
72193
1
KNOB, 3/8-16 X 1.5
9
86010770
87143
2
WASHER, 7/16ID X 1D X .08FLT SS
10
86248380
66433
1
PAD, FLAT LEANING
11
86005630
57022
1
NUT, 3/8-16 HEX NYLOCK THIN SS
12
86071030
140786
1
BRKT, ASSEMBLY, REAR COVER
13
86010780
87162
2
WASHER, 1/4 SPLIT LOCK
14
86271940
57299
2
NUT, 1/4-20 ACORN SS
15
86006560
70083
2
SCR, 5/16-18 X 1 HHCS SS
16
86066940
140891
1
BAR, COVER
