BRUSH DECK LIFT
86037810 CHARIOT® VACUUM 12/16/06
5-8
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86238350
36214
1
GRIP, 3/16 X 1.00 BLUE
2
86076610
38319
1
HANDLE, SQUEEGEE LIFT
3
86257170
72200
1
SWITCH, DPDT, SNAP ACTION
4
86250240
72201
1
PLUNGER, SWITCH, OVERTRAVEL
5
86009560
82053
1
PIN, CLEVIS 1/4 X .63 PLTD
6
86271660
57233
2
NUT, 4-40 HEX NYLOCK
7
86007020
70673
1
SCR, 5/16-18 X 1.25 HHCS SS NP
8
86231570
270105
1
CABLE, SQG LIFT SCRUBPLUS
9
86270830
57023
8
NUT, 5/16-18 HEX NYLOCK SS
10
86276070
70593
2
SCR, 5/16-18 X 3/4 CARRIAGE SS
DELUXE ONLY
11
86223370
66464
4
PULLEY, PLASTIC 3.0 DIA.
12
86073600
66833
1
BRKT, PULLEY RETAINER, SINGLE
13
86231150
09151
5
BUSHING FLANGE, .314 ID X.502 OD
14
86010670
87029
8
WASHER, 5/16 FLAT SS
15
86083500
66832
1
PLATE, PULLEY RETAINER, CORNER
16
86083490
66831
1
PLATE, PULLEY MOUNT, CORNER
17
86276760
70724
4
SCR, 5/16-18 X 1.25 BSHCS SS
18
86066130
89501
1
ASM, HANDLE RETAINER
*(6)
19 OPEN
-
-
-
-
-
20
86091820
140807
1
BRKT, SIDE CHANNEL R
21
86271840
57285
2
NUT, 5/16-18 HEX NYLOCK THIN SS
DELUXE ONLY
22
86068400
14623
1
BRKT, CABLE MOUNT
DELUXE ONLY
23
86083440
66824
1
PLATE, PULLEY MOUNTING, CENTER
24
86277460
70847
1
SCR, 5/16-18 X 5/8 BSHCS SS
25
86259420
87232
2
WASHER, THRUST .51 ID X 1 OD BRO
26
86276010
70580
2
SCR, 4-40 X 1.0 PPHMS
27
86279450
87161
2
WASHER, #6 FLAT SAE PLTD
28
86008650
80604
1
COTTER, 1/4” RING
29
86254280
730331
1
SPACER, 1.00 OD X .32 ID X .375
30
86277130
70795
1
SCR, 5/16-18 X 1.00 CARRIAGE SS
DELUXE ONLY
31
86231760
27725
1
CABLE ASM, SQUEEGEE TC
DELUXE ONLY
* SEE SERIAL NUMBER PAGE
