Page 37
WHEEL-FRONT DRIVE-CHAIN
86037810 CHARIOT® VACUUM 05/19/08
5-36
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86223980
09134
4
SEALED BALL BRNG, 25MM X 52MM
2
86223480
67450
2
RING, 52MM INTERNAL SNAP
3 86219420 41510 1 STEERING,
HUB
4
86224040
730306
1
SHAFT, ASM, DRIVE PIVOT
5
86005510
53810
1
MOTOR, 36V 180RPM GEAR
-
86216210
53820
-
BRUSH SET MOTOR 53810
- 86227440 05261 - ARMATURE
53810
MOTOR
6
86136360
57275
1
NUT, M10X1.5 HEX NYLOCK PLTD
7
86010720
87086
1
WASHER, M10 X 30 PLTD
8
86222730
620038
1
PLATE, DRIVE WHEEL YOKE LH
9
86277320
70828
11
SCR, M10 X 30 HHCS
10
86275640
70515
4
SCR, 3/8-24 X 3/4 HHCS GR5 PLTD
11
86279700
87244
5
WASHER, M10 X 18 FLAT
12
86219620
48106
1
KEY, 1/4 SQ. X .63
13 86007620 730310 1 SPROCKET,
MOTOR
SHAFT
14
86279710
87245
3
WASHER, M8 (2 THK X 26 OD) FLAT
15
86136640
70262
2
SCR, M8-1.25 X 20HHMS PLTD
16
86222710
620036
1
PLATE, CHAIN COVER
17
86279690
87243
12
WASHER, M6 SPLIT LOCK BLK
18
86277340
70830
12
SCR, M6 X 15 HHCS BLK
19
86002730
270085
1
CHAIN, ISO 08B 12.7MM PITCH/LINK
-
86232770
279000
-
CHAIN, OFF-SET LINK 12.7MM
SERVICE ONLY
-
86232780
279001
-
CHAIN, MASTERLINK 12.7MM
SERVICE ONLY
20
86222760
620041
1
PLATE, DRIVE YOKE RH
21 86007630 730311 1 SPROCKET,
DRIVE
WHEEL
22 86002710 270076 1 CHAIN
TENSIONER
23 86224270 730293 1 SLEEVE,
CHAIN TENSIONER
24
86277330
70829
1
SCR, M10 X 45 HHCS
25 86222720 620037 1 PLATE,
BEARING
RETAINER
26
86224330
730294
1
SPACER, 25.5ID X 45OD X 65L
27
86219630
48107
1
KEY, 3/16 SQ X .67
28 86000850 05231 1 AXLE,
DRIVE
29
86219640
48108
1
KEY, 1/4 SQ X 1.5
30
86259940
89275
1
WHEEL, 10X2.5 W/KEYWY GRY, NT
31
86222750
620040
1
PLATE, DRIVE YOKE FRONT
32
86224340
730295
1
SPACER, 25.5ID X 45OD X 43L
33 86222770 620042 1 PLATE,
BEARING
COVER
34
86217720
29269
-
DRIVE ASM, MOTOR
COMPLETE
35
86311040
-
1
SPACER, CHAIN DRIVE AXLE
