Page 61
BATTERY CART - OPTION
86037810 CHARIOT® VACUUM 02/12/08
5-60
REF PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86006930
70514
2
SCR, 5/16-18 X 1.00 BSHCS SS
2 86254290 730338 4 SPACER,
10D
X .343ID, .5 LG
3
86270830
57023
33
NUT, 5/16-18 HEX NYLOCK SS
4
86077010
41517
1
HOUSING, BATTERY CART
5
86010670
87029
7
WASHER, 5/16 FLAT SS
6 86228840 09124 3 BEARING,
FLANGED .314D X .502OD
7
86259410
87206
1
WASHER, THRUST, .51 ID X 1 OD X .063
8
86259400
87205
6
WASHER, THRUST .51 ID X 1 ODBRO
9
86254890
730018
3
SPRING, EXT, .50D X 4.0L
10
86068490
140019
1
BRKT, TRAY CATCH
11 86254280 730331 2 SPACER,
1.00
OD X .32 ID X .375
12
86083120
66442
1
PLATE, BATTERY CART BACK
13
86076600
38318
2
HANDLE, BATTERY CART
14
86004070
36196
2
GRIP, POLISHER HANDEL
15
86276790
70732
4
SCR, 5/16-18 X 1.75 HHCS SS
16
86276690
70715
8
SCR, 5/16-18 X 1.75 CARR SS
17
86199430
040-03
2
CASTER SWIVEL 4” 250# CPCTY
18
86078890
620020
8
PLATE, CASTER SPACER
19
86277130
70795
16
SCR, 5/16-18 X 1.00 CARRIAGE SS
20
86007020
70673
1
SP SCR, 5/16-18 X 1.25 HHCS SS NP
21 86232590 18032 2 CASTER,
4” HARD RUBBER RIGID
22 86001350 140390 2 BUSHING,
SPANNER .435 X 1.10
23
86011020
89202
2
WHEEL, 3” DIA CUSHION RUBBER
24
86271840
57285
2
NUT, 5/16-18 HEX NYLOCK THIN SS
25 86008130 73958 2 SPACER,
3/8OD
X .62W X .312L, AL
26
86274730
70265
2
SCR, 1/4-20 X 3/4 SHCS PLTD
27
86070790
140737
2
BRKT, BATTERY LOCK MOUNT
28 86087340 730339 2 SPACER,
LATCH
GUIDE
29
86070800
140738
2
BRKT, BATTERY TRAY LOCK
30
86271870
57290
2
NUT, 1/4-20 HEX NYLOCK THIN SS
