WHEEL-FRONT DRIVE, GEAR
86037810 CHARIOT® VACUUM 02/21/09
5-38
REF PART
NO. PRV
NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86275190
70377
4
SCR, 3/8-16 X 1.25 HHCS SS
2
86010790
87163
4
WASHER, 3/8 SPLIT LOCK PLTD
3
86002830
27196
1
CABLE TIE, .375 X 24.7
4
86006170
66031
1
PIN, ROLL 1/8” X 3/4”L
5
86223980
09134
3
SEALED BALL BRNG, 25MM X 52MM
6 86219420 41510 1
HUB
STEERING
7
86223480
67450
2
RING, 52MM INTERNAL SNAP
8
86224020
730233
1
SHAFT ASM, DRIVE PIVOT
9
86215440
140920
1
BOX, DRIVE UNIT
10A
86011120
89262
1
WHEEL, 10 X 2, 5 X 1.06 W/KEYWAY
10B
86259920
89273
1
WHEEL, 10 X 2. 5 W/KEYWAY, GRY
OPTION
11
86224440
730387
1
SPACER, 25.51 ID X 45 OD X 39.1 L
12 86222720 620037 1
PLATE,
BEARING
RETAINERX
13
86225810
87506
1
WASHER, ANTI-ROTATION
14
86279710
87245
1
WASHER, M8 (2THK X 26 OD)
15
86136640
70262
1
SCR, M8-1.25 X 20 HHMS PLTD
16
86222770
620042
1
PLATE, BEARING COVER
17
86279690
87243
4
WASHER, M6 SPLIT LOCK BLK
18
86277340
70830
4
SCR, M6 X 15 HHCS BLK
19
86223980
09134
3
SEALED BALL BRNG, .25MM X 52MM
20
86277320
70828
10 SCR, M10 X 30 HHCS
21
86222760
620041
1
PLATE, DRIVE YOKE RH
22
86217730
29276
1
DRIVE MOTOR ASSEMBLY
COMPLETE
-
86216210
53820
-
BRUSH SET MOTOR, 53810 86005510
* SEE SERIAL NUMBER PAGE
