86037810 pg 5-12 and 5-13, Control panel – Windsor CVXE28 User Manual
Page 13
CONTROL PANEL
86037810 CHARIOT® VACUUM 10/23/07
5-12
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86273980
70066
2
SCR, 10-32 X 3/4 PPHMS SS
2
86223740
70872
6
SCR, 1/4-20 X .59 PPHMS SSC
3
86273820
70019
2
SCR, 1/4-20 X 1.25 HHCS SS
4
86277480
70850
3
SCR, 5/16-18 X 1/2 PTHMS SS
5
86008760
80682
1
CONN, 175 DCA GRY W/O TERMS
6
86005810
57245
8
NUT, 1/4-20 HEX NYLOCK SS
7
86070720
140728
1
BRKT, BATT CONN BASIC
8
86271840
57285
3
NUT, 5/16-18 HEX NYLOCK THIN SS
9
86006370
67315
3
RELAY, 36VDC 100 AMP HVY DUTY
10
86010670
87029
6
WASHER, 5/16 FLAT SS
11
86279130
87083
6
WASHER, 5/16 SPLIT LOCK PLTD
12
86271120
57125
6
NUT, 5/16-18 BRASS
13
86005700
57104
5
NUT, 10-32 W/STAR WASHER PLTD
14A
86002760
270092
1
CONTROLLER, CHAIN DRIVE BASIC
CHAIN
DRIVE ONLY
14B 86027740 27911 1 CONTROLLER, GEAR BASIC
* *
GEAR
DRIVE ONLY
15 86008900 80845 1
BOOT,
SEAL-PUSH BUTTON 7/16-28
16
86002010
14942
4
BOOT, 3/8 CIRCUIT BREAKER
BASIC
(3)
DELUXE (4)
17
86005560
54199
1
METER, 36V LED BATTERY
18
86007180
72160
1
SWITCH, EMERGENCY STOP
19
86007190
72161
1
SWITCH KEY DPST
20
86007130
72128
1
SWITCH, DPDT 2-POSITION ROCKER
21
86257280
81371
1
SWITCH, PUSH BUTTON
22
86078180
61481
1
PANEL, VACUUM
23
86251410
67506
3
RELAY, 15A 36V MINI
24
86255900
73538
10
STANDOFF, 6-32 X 5/8 HEX NYL
25
86005530
54154
1
METER, 12-48 VDC LED HOUR
26
86257110
72189
1
SWITCH, 4P3T FIXED POS ROCKER
27
86279300
87134
2
WASHER, #6 LOCK
28
86001910
14606
1
BREAKER, 30A 50VDC CIRCUIT
29
86229770
140805
1
BLOCK, SHUNT MOUNT
30
86257140
72196
1
SWITCH ASM, SEALED PB RND GRN
31 86002000 14717 2
BREAKER,
3 AMP 1681-090-300
BASIC
(1)
DELUXE (2)
32
86250210
66873
1
PLUG, DOME .375
BASIC
(NOT
SHOWN)
33
86230080
141044
2
BREAKER, 22A 250VAC, 50VDC
*(4)
34
86246630
82996
1
LIGHT, INDICATOR, RED
* SEE SERIAL NUMBER PAGE
** CALL MANUFACTURER FOR SERIAL NUMBER
