86037810 pg 5-2 and 5-3, Brush deck – Windsor CVXE28 User Manual
Page 3
BRUSH DECK
86037810 CHARIOT® VACUUM 01/12/09
5-2
REF
PART NO.
PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86272350
66194
2
PIN, DOWEL GROOVE 3/16” X 3/4”L
2
86230700
12536
2
BRUSH, 27.75 X 4.0 OD
3 86227730 03130 2 AXLE,
BRUSH
DRIVE RECIEVER STUB
4
86227720
03129
2
AXLE, BRUSH BEARING STUB
5
86008710
80623
4
RING, 3/4” EXT SNAP H-D
6
86079420
620113
9
PLATE, LOCK W/STUDS
7
86200500
140-11
3
KNOB, RT/TANK
*(12)
WAS 70893
8
86271900
57294
18
NUT, 10-24 HEX NYLOCK THIN SS
9
86319050
-
9
BEARING, SHIELDED 1.125 OD X .500 ID
**
WAS 09019
10 86000920 09055 9 BEARING
FLANGE
11
86079430
620114
1
PLATE, BRUSH DOOR
12
86229010
09162
2
BEARING, 22 X 10 X 6 SS
13
86250740
64118
1
PULLEY, TIMING 5MM HTD 22T 15W
14
86272810
67132
7
RING, 1/2 EXT. SNAP H-D
15
86068460
78943
1
BRACKET, BELT TENSIONER
16
86279630
87212
2
WASHER, .344 ID X .13 OD X .09 T PLT
17
86270830
57023
2
NUT, 5/16-18 HEX NYLOCK SS
18
86277130
70795
2
SCR, 5/16-18 X 1.0 CARRIAGE SS
19 86279350 87140 8 WASHER,
WAVE
1/2ID X 3/4D X .125
20
86092260
29278
1
DECK, BRUSH VACUUM
21
86227710
03128
2
AXLE, BRUSH DRIVER STUB
22
86254330
730401
5
SPACER. .504 ID X .690 OD X .25 L
23
86250750
64119
3
PULLEY, TIMING 5MM HTD 30T, 15W
24
86229450
11050
1
BELT, TIMING, 5MM X 12MM 2-SIDED
25
86278330
70641
1
SHOULDER BOLT, 3/8OD X 3/8L SS
26
86227700
03127
1
AXLE, .50DIA X 14 W/FLATS, JACK
27
86278100
70894
3
SET SCR, 10-32 X .5 SOC CUP PT SS
28
86277650
70895
4
SCR, ¼-20 X 1.25 PFHMS SS
29
86010780
87162
3
WASHER, 1/4 SPLIT LOCK PLTD
30
86010630
87013
3
WASHER, 1/4 ID X 5/8 OD SS
31
86272830
67138
2
RING, 3/8 EXT SNAP
32
86296990
-
1
LABEL, BELT ROUTING, IVAC
*(1)
33
86244500
501107
1
LABEL, BRUSH ORIENTATION
*(1)
* SEE SERIAL NUMBER PAGE
**CALL MANUFACTURER FOR SERIAL NUMBER
