BRUSH DECK LINKAGE
86037810 CHARIOT® VACUUM 09/23/08 5-4
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86273920 70049 4 SCR, 1/4-20 X 1.75 PPHMS SS
2 86063340 270141 1 COVER, DECK SIDE, RIGHT
3 86063350 270142 1 COVER, DECK SIDE, LEFT
4 86228840 09124 6 BEARING, FLANGED .314ID X .502 OD
5 86010670 87029 16 WASHER, 5/16 FLAT SS
6 86270830 57023 28 NUT, 5/16-18 HEX NYLOCK SS
7 86073550 51420 2 BRKT, HEAD ATTACH
8 86259420 87232 10 WASHER, THRUST .51 ID X 1 OD BRO
9 86068410 14838 1 BRACE, ANGLE
10 86088730 14819 1 BAR, TIE, DECK
11 86073560 51421 2 BRKT, HEAD ATTACH
12 86277030 70780 8 SCR, 5/16-18 X 1.25 CARRIAGE SS
13 86276070 70593 8 SCR, 5/16-18 X 3/4 CARRIAGE SS
14 86255000 730385 4 SPRING, EXT. .75 OD X 3.5L
15 86068420 29279 1 BRACKET, SCRUB DECK MOUNTING
16 86010780 87162 4 WASHER, 1/4 SPLIT LOCK PLTD
17 86010810 87191 4 WASHER, 1/4 ID X 1.0 OD FLAT SS
18 86226830 73268 2 SPRING, EXT .68D X 3.00L X .098W
19 86235410 78946 1 EDGING, 3/16” GRIP X 2.0 LG
20 86189050 790464 4 NUT, WELL 1/4-20 HD
21 86236560 43002 1 FOAM, SOUND INSUL, LFT CVR *(2)
22 86236550 43001 1 FOAM, SOUND INSUL, RT CVR *(2)
23 86236570 43003 1 FOAM, SOUND INSUL, UNDR CARR *(2)
24 86068360 141900 1 BRACKET, SCRUB DECK MOUNTING *(3)
25 86072210 141901 1 BRACKET, SPRING TENSIONER *(3)
26 86068370 141903 1 BRACKET, SPRING ANCHOR *(3)
27 86279510 87171 2 WASHER, 3/8 FLAT
28 86271930 57297 2 NUT, 3/8-16 HEX NYLOCK SS
29 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
30 86006560 70083 4 SCR, 5/16-18 X 1 HHCS SS NP
31 86276870 70748 1 SCR, 3/8-16 X 2.50 CARRIAGE SS
32 86276710 70717 6 SCR, 5/16-18 X 2.0 CARRIAGE SS
33 86270900 57037 2 NUT, 1/4-20 WING SS *(12)
34 86276610 70697 2 SCR, 1/4-20 X 1.25 PPHMS SS **
WAS
70049
* SEE SERIAL NUMBER PAGE
** CALL MANUFACTURER FOR SERIAL NUMBER
