VACUUM
86037810 CHARIOT® VACUUM 10/11/08
5-34
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86273780
70015
8
SCR, 1/4-20 X 3/4 HHCS SS NP
2
86197220
87193
2
WASHER, 1/4 X 1.5 FENDER PLTD
3
86086740
730397
1
SCREEN, VAC INTAKE
4
86237960
35362
2
GASKET, VACUUM BOX LID
5
86075570
51460
1
COVER, VAC BOX
6
86272020
57313
5
NUT, 3-32 HEX THIN NYLOCK SS
7
86240300
39718
1
HOSE, GRY VAC, 2.5 X 36
8
86200030
41394
1
HINGE, ACCESS PLATE SENSEI
9
86087370
730398
1
SPACER, VAC BOX LID
10
86005810
57245
4
NUT, 1/4-20 HEX NYLOCK SS
11
86229990
140927
1
BOX, WAV VACUUM
12
86277620
70891
2
SCR, 8-32 X 1/2 HHCS SS
13A 86233120 20019
3 CLAMP,
2.75” WORM GEAR
BASIC ONLY
13B
86233120
20019
4
CLAMP, 2.75” WORM GEAR
DELUXE ONLY
14 86088130 73950 1 STRAP,
CHUTE
15
86247520
53818
1
VAC MOTOR, 36V 1ST TD
-
86290210
-
-
BRUSH SET MOTOR 53818
16
86068440
54208
1
BRACKET, VAC MOTOR MOUNT
17
86236190
34456
1
FITTING, 2 OD MALE X MALE PVC
DELUXE ONLY
18
86247660
54209
1
MUFFLER, SOUND TUBE PLASTIC
DELUXE ONLY
19
86002830
27196
2
CABLE, TIE, .375 X 24.7
DELUXE ONLY
20
86240760
81399
1
HOSE, 2” VAC X 32”
DELUXE ONLY
21
86068110
14028
1
BRACKET, VAC BOX MOUNT
22
86276780
70728
6
SCR, 5/16-18 X 3/4 HHCS SS
23
86270830
57023
2
NUT, 5/16-18 HEX NYLOCK SS
24
86010780
87162
6
WASHER, 1/4 SPLIT LOCK PLTD
25
86235400
78600
2
EDGING, 16” GRIP X 5.50” LG
26
86010670
87029
6
WASHER, 5/16 FLAT SS
27
86006730
70259
2
SCR, 5/16-18 X 1.75 HHCS PLTD
28
86075530
27923
1
COVER, VAC MOTOR
DELUXE ONLY
29
86279130
87083
8
WASHER, 5/16 SPLIT LOCK PLTD
30
86062710
29274
1
DEBRIS CHUTE, WAV
31
86227870
140915
1
BAG, CLOTH VACUUM
32
86215090
140949
1
BAG, PAPER WIDE AREA VAC
33
86224380
730336
2
SPACER, 1 OD X .391 ID X 1.063
34
86238050
36246
1
GASKET, 4.25OD X 3.63ID X .25
35
86240310
39719
1
HOSE, GRAY VAC, 2.25 X 10.0
WAS 39419
36
86238450
36245
1
GROMMET, 3.0 ID X 3.25 GROOVE
37
86234890
270148
1
CUFF, 2.5 SLIP X 2.5 HOSE
38
86009380
81866
1
CUFF, 2” ID VAC-U-FLEX HOSE
39
86081230
62708
1
PLATE, VAC COVER
BASIC ONLY
40
86198000
40067
1
HOSEBARB, 1/8MPT X 3/8 PLASTIC
41
86281680
39486
1
HOSE, 3/8ID NYLOBRAID X 2”
42
86233090
20016
2
CLAMP, 1/4 ID HOSE
43
86257160
72199
1
SWITCH, VACUUM 15” H20 NC/NO
44 86251750 67602 1 RISER,
BUMPER
-
86316200
-
-
VACUUM LINT BRUSH
NOT SHOWN
