BRUSH DECK MOTOR & NOZZLE
86037810 CHARIOT® VACUUM 11/14/07 5-6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86222130 53275 1 MOTOR, 36VDC, 20A, .5HP *(4) WAS 53638
2 86234610 22112 2 COUPLER, .501 ID, 1/2 JAW “D” *(4) WAS 22108
3 86234600 22109 1 COUPLER, SPIDER, SHL070, HYTREL
4 86088100 730403 1 STRAP, BRUSH MOTOR
5 86078040 58006 1 NOZZLE, VACUUM *(5)
6 86276780 70728 2 SCR, 5/16-18 X 3/4 HHCS SS
7 86010630 87013 3 WASHER, 1/4 ID X 5/8 OD SS
8 86010780 87162 3 WASHER, 1/4 SPLIT LOCK PLTD
9 86273780 70015 3 SCR, 1/4-20 X 3/4 HHCS SS NP
10 86010670 87029 2 WASHER, 5/16 FLAT SS
11 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
12 86264940 27051 2 CABLE TIE, 11.38” UL/CSA
13 86277930 70119 2 SET SCR, 1/4-20 X 3/8 KCP DL
14 86271720 57246 4 NUT, 1/4-20 WING NYLOCK ZINC *(5)
15 86238060 36247 1 GASKET, 3.50 W X 25.75L X .19T *(5)
16 OPEN
* SEE SERIAL NUMBER PAGE
