86037810 pg 5-62 and 5-63, Battery cart - option – Windsor CVXE28 User Manual
Page 63
BATTERY CART - OPTION
86037810 CHARIOT® VACUUM 10/23/07
5-62
REF PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86078330
66478
1
PEDAL, BATTERY CART
2
86276070
70593
2
SCR, 5/16-18 X 3/4 CARRIAGE SS
3
86270830
57023
12
NUT, 5/16-18 HEX NYLOCK SS
4
86087800
730307
2
STIFFENER, PEDAL, BATTERY CART
5 86228840 09124 4
BEARING,
FLANGED .314ID X .502OD
6
86259410
87206
6
WASHER, THRUST .51 ID X 1 OD X .063
7
86006560
70083
4
SCR, 5/16-18 X 1 HHCS SS NP
8
86077140
51404
2
LATCH, BATTERY CART
9
86226830
73268
2
SPRING, EXT .68D X 3.00L X .098W
10
86010670
87029
10
WASHER, 5/16 FLAT SS
11 86244280 500934 1 LABEL,
BATTERY CAR OPERATION
12
86276060
70590
4
SCR, 5/16-18 X 2.5 CARR GR5
13 86254280 730331 12
SPACER,
1.00 ODX .32ID X .375
14
86231150
09151
4
BUSHING FLANGE, .314 X .502 OD
15
86259400
87205
8
WASHER, THRUST .51 ID X 1 OD BRO
16
86276690
70715
16
SCR, 5/16-18 X 1.75 CARR SS
17
86077530
51403
2
LINKAGE, LATCH, BATT CART
