86037810 pg 5-18 and 5-19, Frame-lower – Windsor CVXE28 User Manual
Page 19
FRAME-LOWER
86037810 CHARIOT® VACUUM 12/16/06
5-18
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86092510
34440
1
FRAME, MAIN ASM
2
86088760
75458
1
TRAY, SLIDE, LEFT
3
86270830
57023
18
NUT, 5/16-18 HEX NYLOCK SS
4
86071430
140863
1
BRKT, BRACE, RGT FRONT
5
86071120
140811
1
BRKT, TIP BRACE, RIGHT, REAR
6
86010670
87029
4
WASHER, 5/16 FLAT SS
7
86064300
140790
2
PAD, TIPPING BAR
8
86070740
140730
1
BRKT, LINKAGE, RIGHT
9
86276070
70593
16
SCR, 5/16-18 X 3/4 CARRIAGE SS
10
86091420
05251
1
AXLE, REAR WELDMENT
11
86088750
75457
1
TRAY, SLIDE, RIGHT
12 86079320 620101 2 PLATE,
PAD
RETAINER
13
86071130
140812
1
BRKT, TIP BRACE, LEFT, REAR
14
86070750
140731
1
BRKT, LINKAGE, LEFT
15
86070760
140733
1
BRKT, BRACE, LEFT FRONT
16
86279130
87083
4
WASHER, 5/16 SPLIT LOCK PLTD
17
86197040
57264
4
NUT, 5/16-18 HEX ACORN PLTD
18
86079290
620097
2
PLATE, REAR COVER ADJ.
19
86010630
87013
4
WASHER, 1/4 ID X 5/8 OD SS
20
86271870
57290
4
NUT, 1/4-20 HEX NYLOCK THIN SS
21
86276950
70772
4
SCR, 1/4-20 X 3/4 CARRIAGE SS
