86037810 pg 5-24 and 5-25, Pedal platform – Windsor CVXE28 User Manual
Page 25
PEDAL PLATFORM
86037810 CHARIOT® VACUUM 12/16/06
5-24
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86217650 34432 1
DIVIDER
2 86222700 34429 1
PLATFORM
3
86216380
140713
2
BUSHING, 8MM X 10LG CLY
4
86007110
72123
2
SWITCH, 25A SPST 125-250V SNAP
5
86279720
87248
4
WASHER, M4 INT STAR
6
86272040
57503
4
NUT, M3.5 X 2.8 HEX
7
86223580
67502
2
ROD, PIVOT, 8.5MM X 77
8 86222520 34431 1
PEDAL,
BRAKE
9
86277390
70836
4
SCR, M3.5 X 38 PHMS
10
86233170
20054
3
CLAMP, 3/8 NYLON UL/CSA
11
86279730
87249
4
WASHER, M5 INT STAR
12
86277380
70835
4
SCR, M4.8 X 16 PHTF
13 86222510 34430 1
PEDAL,
THROTTLE
14
86254970
730304
2
SPRING, COMP 18MM OD X 83 X 2
15 86222780 620047 2
PLATE,
PIVOT
16
86277360
70833
2
SCR, M6 X 10 PH
17
86274340
70179
11
SCR, M6 X 16 PH
18
86224360
730325
2
SPACER 12.7MM ID X 2.78W X 6L
19 86222810 620050 1
PLATE,
COVER
20
86279140
87085
9
WASHER, M6 SPLIT LOCK DIN127B
21
86288720
57277
2
NUT, M6 NYLOCK PLATED
22
86250280
66135
1
POTENTIOMETER, 5K OHMS
23 86222790 620048 1
PLATE,
THROTTLE
24
86278060
70759
2
SET SCR, M4 X 4MM NP
25
86224350
730305
1
SPACER, 8MM 16L
26
86277370
70834
1
SCR, M5 X 30 SHCS
27 86221850 34433 1
LINK,
THROTTLE
28
86218810
23717
1
HARNESS, TWISTER PEDAL
29 86136310 57086 1
NUT,
M5
HEX
30
86264920
27049
1
CABLE TIE, 7” UL/CSA
31
86224750
73993
1
SPRING, COMP, .480D X .91
*(7)
32
86223260
66085
1
PLUNGER, PLATFORM SWITCH
*(7)
NOTE: Complete platform assembly is available, Part No. 86028310
* SEE SERIAL NUMBER PAGE
