6.2. Displaying circuit Status
The Status Screen displays the On/Off state and selected
parameters for the switched circuits. To display the Status
Screen, type /S and press [Enter]. Note that although the /S
command is available in both User and System Mode, the System
Status Screen includes more information than the User Status
Screen.
When the System Mode is active, the /S command will produce
the screen shown in Figure 6.1, which lists status and parameters
for both circuits, along with Console Port parameters, and
modem command strings. Note that in System Mode, the /S
command will also accept an argument which will display the
User Password for each circuit. To display circuit passwords,
access the System Mode, type /SP and press [Enter].
When the User Mode is active, the /S command produces a
different version of the status screen, which lists the status and
parameters only for the circuit(s) owned by the User password
entered at login. If a separate User Password is assigned to the
other circuit, the User Mode Status Screen will not list the status
for that circuit. In User mode, passwords cannot be displayed.
6-2
RPC-4840N Remote Power Controller; User's Guide
Remote Power Controller v2.0
Site: WESTERN TELEMATIC, INC.
Ckt. | Name
| Status | Boot Delay | Password
| Default |
-----+------------------+---------+------------+------------------+---------+
1
| (undefined)
|
ON
|
5 sec
| (undefined)
|
ON
|
2
| (undefined)
|
ON
|
5 sec
| (undefined)
|
ON
|
-----+------------------+---------+------------+------------------+---------+
Modem Init. String:
ATE0M0Q1&C1&D2S0=1
Modem Disc. String:
(undefined)
Communication Settings: 9600,N,8,1
Command Echo:
On
Disconnect Timeout:
2 Min
Command Confirmation:
On
Automated mode:
Off
"/H" for help.
RPC>
Figure 6.1: System Status Screen (Passwords Hidden)
