5.6. Network Parameters
In order to communicate with the RPC-4840N via network, the
IP Address, Subnet Mask and Gateway Address must first be
defined using the Network Parameters menu. If desired, this
menu also allows you to implement IP Security features, which
restrict command mode access based on the user's IP Address.
Settings for network parameters depend upon the configuration
of your individual network. Please contact your network
administrator for appropriate settings, and then assign parameters
as described in this section.
To access the Network Parameters menu (Figure 5.5), type /N
and press [Enter]. Note that this menu is not available in User
Mode. The following options are available:
1. IP Address: Defines the IP Address for the RPC-4840N
unit. Type 1 press [Enter], and follow the instructions in
the submenu. (Default = undefined)
2. Subnet Mask: Defines the Subnet Mask for the RPC unit.
Type 2 press [Enter], and follow the instructions in the
submenu. (Default = undefined)
3. Gateway Address: Defines the Gateway Address for the
RPC. Type 3 press [Enter], and follow the instructions in
the submenu. (Default = undefined)
4. IP Security: Sets up the IP Security feature as described
in Section 5.6.1.
5. Mac Address: Displays the unit's MAC Address. Note
that this item is not used to redefine the MAC Address.
5-9
Configuration
NETWORK PARAMETERS:
1. IP Address: (undefined)
2. Subnet Mask: (undefined)
3. Gateway Address: (undefined)
4. IP Security
MAC Address: 52-54-40-22-74-0e
Enter Selection or to Exit ...
Figure 5.5: Network Parameters Menu (System Mode Only)
